Heavy-duty pipe clamps and risers engineered for industrial piping systems. Designed to provide reliable load support, vibration control,
| J-Rod Selection | |||||||||||||
| LOAD (lbs) | 0 765 | 766 1491 | 1492 2402 | 2403 3868 | 3869 5663 | 5664 9121 | 9122 13354 | 13355 17775 | 17776 23659 | 23660 28627 | 28628 38103 | 38104 46104 | 46105 60000 |
| J-ROD | 1/2 | 5/8 | 3/4 | 1 | 1 1/4 | 1 1/2 | 1 3/4 | 2 | 2 1/4 | 2 1/2 | 2 3/4 | 3 | 3 1/4 |
| PIPE SIZE | A | B | C | D | H |
| 2 | 4 | 12 | 5 1/2 | 5 | 5 3/16 |
| 2 1/2 | 4 | 12 | 6 3/8 | 5 | 5 7/16 |
| 3 | 4 | 12 | 7 | 5 | 5 3/4 |
| 4 | 4 | 12 | 8 9/16 | 5 | 6 1/4 |
| 5 | 4 | 12 | 9 11/16 | 5 | 6 13/16 |
| 6 | 4 | 12 | 11 5/8 | 5 | 7 5/16 |
| 8 | 4 | 12 | 13 7/8 | 5 | 8 5/16 |
| 10 | 4 | 12 | 17 | 5 | 9 3/8 |
| 12 | 4 | 12 | 18 15/16 | 5 | 10 3/8 |
| 14 | 4 | 12 | 21 | 5 | 11 |
| 16 | 4 | 12 | 23 | 5 | 12 |
| 18 | 7 | 15 | 25 7/8 | 5 1/2 | 13 |
| 20 | 7 | 15 | 28 | 5 1/2 | 14 |
| 24 | 7 | 15 | 33 1/2 | 5 1/2 | 16 |
