Built for Real-World Vertical Support: Custom Riser Clamp Assemblies That Hold the Line

July 21, 2025

When vertical piping in a high-pressure system starts to shift, everything downstream is at risk. Hanger misalignment, accessory failure, and field delays would be the least of your worries when vertical pipe systems experience axial displacement.

That’s where Piping Technology & Products’ custom riser clamp assemblies deliver assurance engineers can count on. With the proper design specifications, PTP can manufacture precision riser clamps that ensure secure and reliable product delivery.

Purpose-Built for Vertical Load Control

Riser clamp assemblies are specifically engineered for vertical pipe systems where axial movement must be restricted. It is not a one-size-fits-all product. Each assembly is fabricated to fit exact pipe diameter, temperature, and load specifications, most commonly for critical process lines in synthetic gas, petrochemical, or tall vertical rack applications.

At its core, the assembly relies on a heavy-duty steel clamp secured around the pipe, working in tandem with thrust plates to manage axial loads.

For high-heat applications, manufacturers utilize A387 alloy steel (rated for service temperatures of 750°F to 1,000°F) and a high-temperature coating that won’t degrade or flake under scorching conditions.

Once installed, the clamp limits movement in the downward direction, ensuring the pipe doesn’t slip under load or due to temperature expansion. Engineers often pair the clamp with spring hangers or sway struts for a complete load path solution.

Real-World Application: Synthetic Gas Plant Retrofit

At the request of a synthetic gas facility, PTP engineered a custom riser clamp assembly for their high-temperature vertical piping. We used Alloy A387, a heat-resistant steel specifically selected for service temperatures reaching up to 1,000°F, to fabricate this assembly.

To ensure performance under thermal cycling, we coated the clamp with a high-temperature industrial-grade coating designed to withstand prolonged exposure without degradation. By preventing vertical slippage during system startup, the clamp maintained alignment integrity and eliminated the risk of early rework or other types of damage to the pipeline.

Common Use Cases for Riser Clamp Assemblies

Riser pipe clamp assemblies serve a critical role in applications where vertical piping must be securely supported and restrained.

Engineers commonly use them on vertical risers in fired heater loops, where high temperatures and axial loads demand reliable restraint. They also support tall structural pipe racks in petrochemical plants, ensuring alignment across multi-level piping systems.

In high-rise and offshore environments, riser clamps provide secure anchoring for firewater systems subject to seismic or dynamic loading. Additionally, LNG facilities rely on them for vertical steam lines that require thermal movement control and long-term integrity.

Key Benefits for Field Execution

PT&P’s custom riser clamp assemblies provide clear advantages for vertical piping systems.

They prevent pipe slippage by firmly securing the line in place, ensuring axial stability under load.

Each assembly is custom-sized to match the exact pipe outer diameter, specified load, and temperature range, eliminating fit-up issues during installation.

PT&P designs these supports to handle pipe sizes up to 48 inches and fabricates them with high-temperature materials and coatings that perform reliably in scorching environments.

Engineers apply Finite Element Analysis (FEA) to optimize steel thickness, reduce excess material, and validate structural integrity.

By managing design, fabrication, and delivery in-house, PT&P minimizes handoffs and reduces the risk of delays or errors throughout the supply chain.

Why Engineers Choose Riser Clamp Assemblies

Engineers value this clamp for its precision and structural integrity. Load ratings are validated through FEA, ensuring that the clamp can stand against almost any surprise event. For jobs with elevated temperatures or non-standard loads, our custom approach removes guesswork from spec compliance.

Why Project Managers Chose Riser Clamp Assemblies

What sets these clamps apart is how they minimize scope creep.

When clamp assemblies are properly designed from the start, there’s no field modification, no install surprises, and fewer RFIs. The result: less rework, better schedule control, and a clear value add during procurement planning.

Other Items Often Purchased with Riser Pipe Clamp Assemblies

Talk to an Engineer

Need a riser clamp that fits your piping system? Our team is ready to review your load, pipe size, and environment to build the right assembly fast.

Request a Quote or Talk to an Engineer today.

Hold-Down Pipe Clamps with PTFE Slide Plates Offer Secure, Low-Friction Thermal Movement

June 9, 2025

Allow Axial Movement While Maintaining Vertical Restraint

Pipe hold-down clamps secure the pipe in place while allowing it to expand, contract, and shift naturally without stress concentration or misalignment.

Thermal expansion can disrupt alignment, overstress anchors, and damage coatings, particularly on large-diameter pipes measuring 20 inches or more in diameter. Without proper restraint, pipe systems can buckle supports or shift pipe saddles, triggering high-cost field repairs.

In compressor stations, wastewater treatment facilities, pipeline terminals, petrochemical plants, and LNG terminals, slight misalignment can threaten structural integrity. Long lead times on specialized supports only aggravate the situation.

That’s why engineers choose pipe hold down clamps that install cleanly, eliminate the effects of stress, and account for thermal expansion.

HD-2 and HD-3 Pipe Hold Down Clamps with PTFE Slide Plates Manufactured by Piping Technology

Our HD-2 and HD-3 pipe hold-down clamps are designed to provide secure vertical restraint and controlled axial movement of the pipe.

These hold-down clamps are designed for pipes with diameters of 20 to 30 inches and are manufactured from carbon steel. The clamp saddle and base are lined with PTFE (polytetrafluoroethylene) and 25% glass fiber-filled slide plates, creating a durable, low-friction sliding surface.

The result: restrained vertical load with smooth axial movement, while restraining vertical and lateral movement in the piping system.

How it works:

PTFE-lined (or graphite) surface allows low-resistance axial pipe movement without binding or buckling
Glass fiber fill reinforces the sliding surface under load
Carbon steel body ensures long-term structural stability
Typically installs using a bolt-down configuration, minimizing the need for field welding

Case Study: Rush Delivery to South Dakota Natural Gas Pump Station

A natural gas pump station in South Dakota required large-diameter hold-down clamps that could withstand thermal cycling, vibration, and harsh outdoor exposure.

Project Specs:

Pipe Diameter: 20″ to 30″
Quantity: 22 custom-fabricated pipe hold down clamps
Material: Carbon steel with 25% glass-filled PTFE liners
Application Environment: Outdoor station, high-vibration compressor skid
Turnaround: One-week rush fabrication, shipped on time, zero field modifications

The hold-down clamps arrived installation-ready with clear labeling and documentation: no grinding, no guesswork, no schedule slip.

We pride ourselves on being the manufacturing leader for large-scale projects, providing rapid delivery to meet construction milestones. We offer a 24-hour emergency support hotline for critical situations:

Where Pipe Hold Down Clamps Work Best

Natural gas compressor and pump stations
Petrochemical and chemical processing plants
LNG terminals and cryogenic transfer lines
Structural steel pipe racks and skids for space aviation, semiconductor, and battery plants
Long-run pipe systems requiring expansion, travel control

Field Benefits of Pipe Hold Down Clamps

Controls axial, vertical, and lateral movement, where uncontrolled movement can damage expensive equipment or cause safety hazards.
Reduces clamp friction and wear with PTFE-lined saddle
Minimizes rework and installation risk with a bolt-in design
Installs fast, no welding or fit delays
Engineered for vibration control to dampen and restrict pipe vibration, preventing fatigue or failure.
Built to spec for 20- to 30-inch diameter pipe
Shipped labeled and documented to streamline the installation

Engineer’s Take: Designed for Restraint

These hold clamps meet ASME and ASTM material and performance specifications, and every hold-down clamp undergoes rigorous internal quality checks and inspections. The PTFE slide plates enable axial movement of pipes without binding in piping systems and protect coatings. Engineers use them to control the piping system and meet ASME code requirements on critical long-run systems. For a pipe stress engineer, the use of hold-downs with PTFE can be a valuable tool in directing and managing the thermal expansion of the piping system.

Project Manager’s Take: Built to Install Without Surprises

When project timelines are tight, you don’t have room for guesswork. These pipe hold down clamps ship fast, even in a rush, and arrive ready to bolt in place. No RFI triggers, no field-fit delays. Just labeled, documented, fabrication-verified components that hold up during commissioning and beyond. Less risk, fewer delays, and lower total install cost.

Commonly Paired Products

Pipe Shoes with PTFE Slide Plates – For guided thermal movement on supports
Spring Hangers – To handle vertical load shifts in dynamic systems
Pipe Anchors and Guides – For directional restraint and thermal path control
Insulated Pipe Supports – For high-temp systems needing coating protection
Adjustable Pipe Supports – Allowing for on-site adjustments at the time of installation when pipe elevations are still not finalized

Talk to an Engineer

Piping Technology has one of the largest engineering departments in the piping support manufacturing industry. If you think pipe hold-down clamps would be a good solution for your next project, but would like to discuss it with our technical engineers, then contact us today!

If you are ready to move forward with a quote for your next project, then send us an RFQ for pipe hold down clamps.
Contact Us

If you are ready to move forward with a quote for your next project, then send us an RFQ for pipe hold down clamps.
Request a Quote

Adjustable Pipe Saddles for Stabilizing Heavy Horizontal Piping Under Dynamic Loads

May 23, 2025

30" Dia. Adjustable Pipe Saddle Supports Designed for an Oil Refinery

Designed to prevent deformation and reduce stress at key support points, adjustable pipe saddles deliver fixed, stable support where movement is not an option.

Chosen When Precision Elevation and Structural Rigidity Are Non-Negotiable

Heavy piping systems under load can shift, sag, or deform, especially when unsupported over distance or exposed to vibration, thermal change, or movement, putting your process-critical fixed equipment at risk . Adjustable pipe saddles are engineered to eliminate those risks.

By locking the pipe into a fixed elevation and anchoring directly into structural steel or concrete, these supports maintain piping system alignment reduce localized stress prevent any long-term deformation in critical systems.

Why Engineers Choose Adjustable Pipe Saddles Over Adjustable Pipe Stands

Engineers will usually specify adjustable pipe saddles when systems require exact pipe elevation, concentrated load handling, and rigid structural anchoring that won’t shift under pressure. For projects where pipe supports must prevent movement entirely, rather than allow for it, saddles are the reliable, constructability built solution.

Adjustable Pipe Saddles vs. Fixed Pipe Saddles: What’s the Difference?

Adjustable Pipe Saddles

Adjustable pipe saddles feature a fixed-height saddle (the curved cradle that supports the pipe), but are mounted on adjustable vertical supports or stanchions. This allows the elevation to be fine-tuned during installation to match field conditions, which is ideal when construction tolerances, structural discrepancies, or elevation mismatches are likely.

How It Works:

A seamless center pipe section can be rotated to raise or lower the saddle height.
Pre-drilled base plates make anchor bolt installation fast and consistent.

Carbon steel construction with red oxide primer or hot dipped galvanized coating ensures corrosion resistance in harsh environments.

Fixed Pipe Saddles

Fixed pipe saddles are completely static supports. Both the saddle and its structural stanchion are built to a specified height, with no option field adjustability. They’re designed when exact elevations are known in the piping system, to achieve maximum stability and zero movement under load.

Case Study: Adjustable Pipe Saddles for an Oil Refinery Retrofit in Michigan

When an EPC firm was retrofitting sections of a Midwestern oil refinery, they needed the infrastructure to support large process lines with varying elevations across aging foundations. We were able to design and manufacture custom adjustable pipe saddles for 24″ and 30″ diameter piping, fabricated from carbon steel and coated with red oxide to withstand Michigan’s seasonal shifts.

Adjustable Pipe Saddle Product Specs:

Pipe Sizes: 24″ and 30″ OD
Support Height: Adjustable from 40″ to 42″
Material: Carbon steel, red oxide finish
Adjustment Mechanism: Rotatable center pipe
Delivery: Shipped within two weeks

The EPC team completed the install without site rework, saving time and ensuring alignment across uneven foundation grades.

Ideal Applications for Adjustable Pipe Saddles

Adjustable saddle supports are frequently used in:

Oil and gas refineries
LNG terminals and gas processing plants
Petrochemical and chemical plants
Power generation and utility facilities
Pipe rack and sleeper systems in retrofit projects

Any application requiring elevation flexibility or working around existing steel is a strong fit.

Why Engineers Choose Adjustable Pipe Saddles

Height adjustability eliminates field rework
Faster installation that requires no welding or on-site modifications
Pre-drilled base plates ensure bolt-down accuracy.
Code compliant that meets ASME B31.3 and MSS-SP (Manufacturers Standardization Society Standard Practices) standards.
Corrosion-resistant with protective coatings
Available fast and quick turnaround to meet schedule demands

Why Engineers Choose Piping Technology & Products

Engineers trust us to supply them with adjustable pipe saddle that are:

Load-tested and fabricated to custom project specs
Adjustable within tight tolerances
Available with full CAD support, drawings, and stamped calculations
Built to meet ASME, ASTM (American Society for Testing and Materials), and NACE (National Association of Corrosion Engineers) standards.

The rotatable center section allows for precise elevation control, enabling engineers to dial in exact support heights without adding field modifications or compromising load-bearing integrity.

Why Project Manager’s Choose Piping Technology & Products

Project Manager’s value adjustable pipe saddles because they:

Avoid schedule slip from misaligned piping or uneven foundations
Reduce field RFIs and last-minute design changes
Minimize costly rework and field welding.
Fit into value-engineered packages that reduce labor and install time.

Adjustable pipe saddles make a project manager’s job easier, are built for changing field conditions, and are backed by a team that picks up the phone when it counts, 24/7. Our responsive engineering and quick-ship capabilities support fast-paced schedules, and our ability to align with field constructability needs—including work package-based production for module or scope schedules—helps keep projects on track from procurement to commissioning.

Adjustable Pipe Saddles are Usually Paired With:

Pipe Shoes: for insulation or wear protection
Variable Spring Hangers: for dynamic load balancing
Anchor Clamps: for fixed points and thrust loads
Embed Plates: for secure base installation in concrete

We are the only manufacturing company that engineers, fabricates, and ships all your pipe support needs from our manufacturing facility in Houston, Texas.

Talk to an Engineer

Are adjustable pipe saddles right for your next project? Talk with our engineering team about sizing, specs, and turnaround times.

Request a Quote
PT&P REF. ORIGINAL POST 03102013

Heavy-Duty Pipe Saddles: Precision Support for Heavy Pipes, Long Spans, and Dynamic Load Conditions

May 5, 2025

42" Large Bore Pipe Saddles — 42″ Large Bore Pipe Saddles

Reliable Load Transfer Without Installation Headaches

Pipe saddles are critical solutions for securing heavy pipelines and managing load transfer to structural elements. More than just supports, our engineered pipe saddles help reduce localized stress and maintain system alignment by stabilizing the pipe and minimizing deformation at critical support points.

What is a Pipe Saddle?

A pipe saddle consists of a curved base designed to partially wrap around a pipe, paired with a vertical stanchion that anchors it to a supporting structure. Pipe saddles are essential for:

Managing high loads over long pipe spans.
Preventing deformation, wear, and stress fractures.
Ensuring system stability when support points are limited.

Piping Technology & Products manufactures pipe saddles to exact specifications using durable materials such as carbon steel, with options for specialized coatings to resist corrosion. Whether you need a standard design or a custom configuration, we deliver saddle supports built for your project’s diameter, load, and structural interface requirements.

Case Study: Custom Pipe Saddles for a Midstream Gas Facility

For a midstream natural gas project in the Midwest, Piping Technology designed and delivered a large order of custom-fabricated pipe saddles:

Pipe Size: 36-inch diameter.
Load Requirements: Engineered for substantial dynamic loads.
Finish: Hot-dip galvanized for long-term outdoor durability.
Compliance: Designed to meet ASME standards.

Our in-house engineering team worked directly with the EPC contractor to accelerate the design and fabrication cycle. This proactive collaboration ensured a perfect field fit, eliminated rework, and helped keep the overall project on schedule, addressing a key priority for EPC managers while avoiding any installation setbacks.

Designed for Midstream Energy Demands

In the midstream oil and gas sector, performance, quality, and reliability are non-negotiable. Piping systems must withstand:

Thermal expansion and contraction across long distances.
Environmental exposure to moisture, temperature fluctuations, and corrosive agents.
Variable load conditions over the system’s operational lifespan.

Our pipe saddles deliver the durability and stability midstream operators require, minimizing downtime risks and safeguarding critical infrastructure.

Additional Solutions for Midstream Applications

In addition to heavy-duty saddles, PT&P offers a full range of custom supports engineered for the challenges of midstream energy projects:

Constant and Variable Spring Hangers: Manage vertical movement due to thermal expansion.
Pipe Shoes
Pipe Anchors and Guides: Control axial loads and direct pipe movement safely.
Cryogenic Insulated Supports: Specialized designs for LNG and low-temperature systems.
Custom U-bolts and Clamps: Engineered fastening solutions for complex configurations.

Each product is manufactured to meet project-specific load, movement, and environmental requirements, ensuring seamless system integration.

Why Project Managers Trust Piping Technology

When you partner with us, you get more than just products; you gain a reliable team committed to helping you deliver flawless projects.

We offer:

Engineering Expertise: Real-time collaboration with seasoned engineers.
Proven Product Quality: Materials and manufacturing processes that meet or exceed ASME, ASTM, and API standards.
Manufacturing: Deep manufacturing expertise to deliver scale, large volume, fastest time to market customized solutions with a sharp focus on constructability and site needs.
On-Time Delivery: A proven track record of meeting tight project timelines.
Cost Efficiency: Competitive pricing without compromising quality or performance.
Responsive Support: Fast answers to RFIs, urgent field issues, and design changes.

For Project Managers, that means reduced risk, minimized rework, and higher confidence in project success.

Get the Right Saddle Support for Your Next Project

Talk to an engineer today to discuss your application and receive a custom solution for your project needs.

Talk to an engineer today or Request a Quote

Trapeze Roller Hangers for a Food Processing Facility

December 3, 2024

Type:	Trapeze Roller Hangers
Size:	2-5/8″ to 16-3/8″ L x 4″ to 16″ Dia. \| 600 to 3,970 lb. Load
Material:	Cast Iron
Testing:	Standard quality control inspections

Piping Technology & Products designed these trapeze roller hangers for a food processing facility in Kentucky. Rollers are typically employed when axial movement at the support location results in swing angles exceeding 4 degrees.

The rollers are available in lengths ranging from 2-5/8″ to 16-3/8″ for pipe diameters between 4″ and 16″. Constructed with cast iron rolls and sockets along with steel roll rods, they ensure durability and adaptability for a range of applications.

The rollers are oriented horizontally for the suspension of pipes using two all threaded vertical rods and hex nuts for vertical adjustments, effectively accommodating longitudinal movement caused by thermal expansion or contraction. They are designed for load ratings ranging from 600 to 3,970 lbs.

Standard quality control inspections were conducted prior to shipment to ensure compliance with industry standards. Similar applications by Piping Technology & Products include:

Wastewater facilities
Food Service
Bridges
Cooling Towers
Refineries
Gas Plants

In addition to standard rollers, we offer machinable rollers made from specialized non-metallic materials, such as polyurethane and polyurethane foam. These materials can be custom-contoured to meet unique project specifications using our in-house manufacturing capabilities.

For larger roller assemblies, Piping Technology & Products provides complete customization options, including finite element analysis (FEA) to ensure the design meets the exact requirements of your piping system. Whether you need standard or customized solutions, our team is equipped to deliver quality products tailored to your application.

PT&P REF. ORIGINAL POST 04242017

14” Diameter Pipe Shoe Assemblies for a Refining Project in Saudi Arabia

April 2, 2024

Piping Technologies & Products fabricated these special designed Split-T pipe shoes using a Figure 50 “two-bolt pipe clamp” with added gusset plates welded beneath the clamps for a refining project in Saudi Arabia. The gusset plates are added to increase the vertical load-carrying capacity. The pipe shoes are 4″ height x 15.5″ wide x 18″ long and were fabricated from A36 carbon steel with a hot-dipped galvanized finish. They are designed for a pipe size of 14″ with an operating temperature from -29°C to 316°C. The pipe shoes are capable of supporting an operating load of 34,000 lb.

We provide such products in a “clamp-on-shoe” configuration to meet the needs of client applications where welding the pipe shoe onto the process line is prohibited. Depending on the client’s specifications, we can design and manufacture these shoes without a finish (black) or various painted finishes in place of hot-dipped galvanizing to expedite the delivery of the order. We can manufacture these clamp-on-pipe shoes with different metallurgies, such as 304 or 316 stainless steel, to accommodate high temperatures or cryogenic applications depending on the project’s needs. This basic pipe support is used in industries ranging from automotive, petrochemical, LNG, and refining in almost every major processing unit to maintain pipe elevations and handle loads imposed by media movement.

PT&P REF. ORIGINAL POST 07112016

PT&P Roller Hangers for an Aviation Facility in California

December 26, 2023

Type:	Roller Hangers
Size:	12″ Wide and 15″ Tall
Material:	Cast Iron & Carbon Steel
Design:	965 lbs. Operating Load & 10″ Pipe Size
Testing:	Standard Quality Control

These Fig. 195 roller hangers were designed by PT&P for an aviation facility in California. They measure 12″ in width and 15″ in height. The rollers are fabricated from cast iron, with the yoke, roll rod, and hex nuts from carbon steel. The units are designed for a pipe size of 10″ and an operating load of 965 lbs. Standard quality control tests were performed prior to shipment. Roller hangers are used for the suspension of pipe from a single rod where axial movement may occur because of expansion or contraction. These are often used on bridges where pipelines cross waterways such as rivers and bayous. If there is extensive traffic, they can be used in conjunction with variable springs to accommodate such factors as vibration, wind, and other external factors. This particular job is an excellent demonstration of our ability to support quick turn request to meet the needs of our clients as it was shipped before the contract date in less than a week’s time.

Our roots are deeply embedded in the petrochemical, power, energy, and refining sectors. We remain adaptable, constantly seeking opportunities to contribute to pivotal projects. Our recent diversification into various industry verticals encompasses participation in both private and public sector space exploration. Additionally, we play a pivotal role in the flourishing 11.2 billion-dollar data center industry, driven by advancements in AI and its widespread adoption.

Time-to-market is a paramount consideration for our projects. Leveraging our Houston-based manufacturing facility, we stand out as a market leader, possessing the capability to support large volumes within tight timeframes. This agility is particularly crucial for the time-sensitive nature of semiconductor, pharmaceutical, EV battery, and automotive production facilities.

PT&P REF. ORIGINAL POST 04022018

Standard Pipe Support Components Available on Amazon

September 21, 2022

Need a standard product quickly? Or know what you need and don’t need a quote? Skip the line and order through Amazon. From forged carbon steel turnbuckles and light or heavy 2-bolt, 3-bolt pipe clamps, riser clamps to long tangent u-bolts, we stock standard sizes for your quick-turn orders.

*If you need assistance, we are always available 24×7 via our emergency service or just send an email to info@pipingtech.com.

Fig. 30 Forged Carbon Steel Turnbuckle	Fig. 60 Heavy Two-Bolt Pipe Clamp
Fig. 70 Light Three-Bolt Pipe Clamp	Fig. 80 Heavy Three-Bolt Pipe Clamp
Fig. 90 Riser Clamp	Fig. 100 Long Tangent U-Bolt
Piping Technology & Products, Inc. Expansion Joint (85 PSI)	Piping Technology & Products, Inc. Expansion Joint (150 PSI)
Piping Technology & Products, Inc. Expansion Joint (300 PSI)

Pipe Saddles Custom Designed for LNG Facility

August 3, 2022

Type:	Heavy-Duty Pipe Saddles
Size:	Up to 48” Diameter
Material:	A36 Carbon Steel
Testing:	Q.C. Visual Inspection \| Pipe Dimensional Tests

This week’s featured product, Piping Technology & Products, Inc. custom-designed heavy-duty pipe saddles for an LNG facility in Louisiana. The pipe saddles are part of a large liquefaction project and range in size. The largest pipe saddle will support a 48” diameter pipeline. They are fabricated utilizing A516 Gr70N low-temperature carbon steel base plates, and web plates. Standard Q.C., visual inspection with pipe dimensional tests were performed prior to shipment. A pipe saddle is a structure consisting of a saddle and integral base used to support the pipe by transmitting the load or forces to the adjacent structure. Since we are a custom fabrication shop, we specialize in the design and manufacture of pipe shoes and saddles to accommodate sloping lines, pipe elbows, hot and cold temperature lines, as well as storage tanks and pressure vessels. In addition to pipe saddles, we have also supplied a wide variety of pipe supports to LNG projects, as well as, Floating Rings. Below is just a brief list of supports supplied to LNG projects from our product portfolio:

Varibale Assemblies

Constants Assemblies

Pipe Hanger Hardware

Slide plates and wear pads

Snubbers, Sway braces

Cryogenic Insulated Shoes-G10 as well as PUF

Insulated Trunnions

Adjustable Pipe Stands

Our products have gone into all key components of LNG facilities ranging from the liquefaction plant, the flare lines, loading lines, the terminals, and storage tank facilities.

PT&P REF. ORIGINAL POST 01082020

Heavy-Duty Pipe Clamps for Service at a Coal-Fired Power Plant

April 26, 2022

These clamps were installed in a coal-fired power plant on the Ohio River, and this plant features one of the largest smokestacks in the world at 1038 feet. For this plant, sub-bituminous coal is used in conjunction with steam turbine technology to generate thermal power with over 10k gigawatts of output annually.

Heavy-duty pipe clamps are bolted around the pipe and connect to the remainder of the pipe hanger assembly. This assembly included a Fig. 30 forged turnbuckle, which is also available on Amazon as a stocked item. PT&P maintains an extensive inventory of pipe clamps required for pipe hangers and support assemblies. These Fig. 80 three-bolt pipe clamps are fabricated from carbon steel and for this project, the pipe clamps were painted with a red oxide primer. These pipe clamps are designed for 36” diameter pipelines and are recommended for suspension of cold pipelines or hotlines where little or no insulation is required and are capable of supporting both horizontal and vertical piping. A visual inspection test along with “sample pipe” dimensional checks were conducted prior to shipment.

Such clamps can be used in any type of piping system for various industries such as chemical, biofuel, food processing, and refining plants. We have the ability to get such products at your jobsite overnight given our pipe hanger hardware inventory of over 1 million pounds, our quick order system through Amazon, and 24/7 manufacturing and engineering support provided by our teams around the clock.

Do you need this exact pipe support? Skip the line and order our standard pipe support components on Amazon. From forged carbon steel turnbuckles and light or heavy 2-bolt, 3-bolt pipe clamps, riser clamps to long tangent u-bolts, we stock standard sizes for your quick-turn orders.
